Overview

Half the size of a laptop and weighing less than 1 kg, the Nera WorldPro 1000 meets the toughest demands for portability. Built for persistent travel and bumpy rides, the terminal can be dropped onto concrete without breaking and works just as well in a dusty desert as in a humid rain forest.

Specifications

Data Rates
Transmit:  240 kbps
Receive:  384 kbps
Streaming:  32, 64 kbps symmetrical

Interfaces
Ethernet:  (Nera WorldPro 1010)
USB:  (Nera WorldPro 1000) 1 connector, data rate up to 12 Mbps Bluetooth:  Built-in, data rate 432.6 kbps
ISDN:  1 RJ-45 connector for voice handset

Power
Input voltage:  100 - 240 VAC +/-10%, 50 -60 Hz 800 mA
Output voltage:  12 VDC -10%/+30% feed

Environmental
Storage terminal:  -40°C - +80°C
Storage battery:  -20°C - +40°C
Operational:  -20°C - +55°C, 95% non-condensing humidity at 40°C Light:  500 W/m2 infrared, 54 W/m2 ultra violet
Visible sunshine:  1120 W/m2 MIL-SPEC 810E 505-3
Sealing class:  IP44

Antenna performance
Gain:  Tx 8.5 dBic Rx 8.5 dBic
Beam width:  +/- 30°

Battery
Typical use:  5 hours, 20% activity factor
Time to full charge:  3 hours

Physical Data
Weight 995g including battery
Dimensions 20 x 15 x 4.5 cm
Distance split configuration antenna unit - interface unit:  max. 30 m
Distance interface unit - Bluetooth device:  max. 10m for Nera WorldPro 1000 / max. 30m for Nera WorldPro 1010
